13-024QMTB00A1-S
Size (inch):
2,4
Active Area (mm):
36.72 x 48.96
Resolution:
240 x 320
Outline Dimension (mm):
42.72 x 60.25 x 2.45
Interface:
MCU8080 interface -
13-028QMTB00C0-S
Size (inch):
2,8
Active Area (mm):
43.2 x 57.6
Resolution:
240 x 320
Outline Dimension (mm):
50 x 69 x 2.55
Interface:
MCU parallel / RGB -
WF35LSIACDNN0
Size (inch):
3,5
Active Area (mm):
70.08 x 52.56
Resolution:
320 x 240
Outline Dimension (mm):
76.9 x 63.9
Interface:
RGB -
WF35LSIACDNT0
Size (inch):
3,5
Active Area (mm):
70.08 x 52.56
Resolution:
320 x 240
Outline Dimension (mm):
76.9 x 63.9
Interface:
RGB -
WF35LSIACDNCA
Size (inch):
3,5
Active Area (mm):
70.08 x 52.56
Resolution:
320 x 240
Outline Dimension (mm):
76.9 x 63.9
Interface:
RGB -
13-035QMTB0GB0-S
Size (inch):
3,5
Active Area (mm):
70.08 x 52.56
Resolution:
240 x 320
Outline Dimension (mm):
76.9 x 63.9 x 3.15
Interface:
Parallel RGB-24 bit / 54pin -
WF43GSIAEDNN0
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43GSIAEDNG0
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSIAEDNNB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSIAEDNTB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSIAEDNGB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSZAEDNNB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSZAEDNTB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43HSZAEDNCB
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
13-043YMTB0GA8-S
Size (inch):
4,3
Active Area (mm):
95.04 x 53.856
Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2 x 2.9
Interface:
Parallel RGB-24 bit / 40pin -
13-050WMTB00B0-S
Size (inch):
5,0
Active Area (mm):
108.0 x 64.8
Resolution:
800 x 480
Outline Dimension (mm):
118.4 x 77.45 x 3.0
Interface:
Parallel RGB-24 bit / 40pin -
WF57ESIACDNN0
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
320 x 240
Outline Dimension (mm):
141.12 x 101.55
Interface:
RGB -
13-057QMTB00B1-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
320 x 240
Outline Dimension (mm):
144 x 104.6 x 12.8
Interface:
Parallel RGB-18 bit / 33pin -
13-057QMTB00C1-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
320 x 240
Outline Dimension (mm):
144 x 104.6 x 12.8
Interface:
Parallel RGB-18 bit / 40pin / LED.Dr -
13-057VMTB00B1-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
640 x 480
Outline Dimension (mm):
144 x 104.6 x 12.8
Interface:
Parallel RGB-18 bit / 33pin -
13-057VMTB00C1-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
640 x 480
Outline Dimension (mm):
144 x 104.6 x 12.8
Interface:
Parallel RGB-18 bit / 40pin / LED.Dr -
13-057VMTB00C2-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
640 x 480
Outline Dimension (mm):
144.0 x 104.6 x 15.28
Interface:
Parallel RGB-18 bit / 40pin / LED.Dr -
13-057VMLB00B1-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
640 x 480
Outline Dimension (mm):
144 x 104.6 x 12.8
Interface:
LVDS-6 bit / 20pin -
13-057VMLB00B4-S
Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
Resolution:
640 x 480
Outline Dimension (mm):
144 x 104.6 x 15.28
Interface:
LVDS-6 bit / 20pin -
WF70GSIAGDNNA
Size (inch):
7,0
Active Area (mm):
154.08 x 85.92
Resolution:
800 x 480
Outline Dimension (mm):
165 x 100
Interface:
RGB -
13-070WMTB00A1-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 3.5
Interface:
Parallel RGB-18 bit / 40pin / LED.Dr -
13-070WMTB00B0-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 5.05
Interface:
Parallel RGB-18 bit / 40pin -
13-070WMTB00B1-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 5.05
Interface:
Parallel RGB-18 bit / 40pin -
13-070WMLB00A1-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 3.5
Interface:
LVDS-6 bit / 20pin / LED Dr -
13-070WMLB00B0-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 5.05
Interface:
LVDS-6 bit / 20pin -
13-070WMLB00B1-S
Size (inch):
7,0
Active Area (mm):
153.6 x 86.64
Resolution:
800 x 480
Outline Dimension (mm):
165.0 x 104.0 x 5.05
Interface:
LVDS-6 bit / 20pin -
WF70BSIAHLNN0
Size (inch):
7,0
Active Area (mm):
154.2114 x 85.92
Resolution:
1024 x 600
Outline Dimension (mm):
168.5 x 102
Interface:
LVDS -
WF70BSZAHLNN0
Size (inch):
7,0
Active Area (mm):
154.2144 x 85.92
Resolution:
1024 x 600
Outline Dimension (mm):
168.5 x 102
Interface:
LVDS -
13-070XILB0GH1-S
Size (inch):
7,0
Active Area (mm):
154.21 x 85.92
Resolution:
1024 x 600
Outline Dimension (mm):
164.9 x 100.0 x 4.6
Interface:
LVDS-6 bit / 20pin / LED Dr -
13-070XILB0GH6-S
Size (inch):
7,0
Active Area (mm):
154.21 x 85.92
Resolution:
1024 x 600
Outline Dimension (mm):
164.9 x 100.0 x 5.05
Interface:
LVDS-6 bit / 20pin -
13-080GILB00A0-S
Size (inch):
8,0
Active Area (mm):
162.05 x 121.54
Resolution:
1024 x 768
Outline Dimension (mm):
183.0 x 141.0 x 6.3
Interface:
LVDS 6bit/20pin -
13-080BIEB0HB1-S
Size (inch):
8,0
Active Area (mm):
194.4 x 58.32
Resolution:
1024 x 768
Outline Dimension (mm):
208.0 x 73.0 x 6.5
Interface:
LVDS 8bit interface/LED Dr -
WF101FSAAPLNN0
Size (inch):
10,1
Active Area (mm):
216.96 x 135.6
Resolution:
1280 x 800
Outline Dimension (mm):
230.56 x 155.01
Interface:
LVDS -
13-101XMLA00C9-S
Size (inch):
10,1
Active Area (mm):
222.72 x 125.22
Resolution:
1024 x 600
Outline Dimension (mm):
235.0 x 143.0 x 9.5
Interface:
LVDS-6 bit / 20pin ( K ) -
13-101ZIEB0HH1-S
Size (inch):
10,1
Active Area (mm):
216.96 x 135.6
Resolution:
1280 x 800
Outline Dimension (mm):
229.46 x 149.1 x 4.80
Interface:
LVDS-8 bit / 30pin / LED Dr -
13-101HIEA0RA0-S
Size (inch):
10,1
Active Area (mm):
216.576 x 135.36
Resolution:
1900 x 1200
Outline Dimension (mm):
229 x 153 x 2.5
Interface:
LVDS dual 8bit -
13-104SMLE00C1-S
Size (inch):
10,4
Active Area (mm):
211.2 x 158.4
Resolution:
800 x 600
Outline Dimension (mm):
243 x 184 x 6.5
Interface:
LVDS-6/8 bit / 20pin -
13-104GVEB0GA0-S
Size (inch):
10,4
Active Area (mm):
210.432 x 157.824
Resolution:
1024 x 768
Outline Dimension (mm):
225.5 x 176.3 x 8.4
Interface:
LVDS-6 or 8 bit / 30pin -
13-104GMLB00B0-S
Size (inch):
10,4
Active Area (mm):
211.2 x 158.4
Resolution:
1024 x 768
Outline Dimension (mm):
236 x 174.3 x 5.7
Interface:
LVDS-6 bit / 30pin -
13-121GMLC00B0-S
Size (inch):
12,1
Active Area (mm):
245.76 x 184.32
Resolution:
1024 x 768
Outline Dimension (mm):
279 x 209 x 9.0
Interface:
LVDS 6/8 bits / 20pin -
13-121GMLC00B1-S
Size (inch):
12,1
Active Area (mm):
245.76 x 184.32
Resolution:
1024 x 768
Outline Dimension (mm):
279 x 209 x 9.0
Interface:
LVDS 6/8 bits / 20pin -
13-121ZVLB00A1-S
Size (inch):
12,1
Active Area (mm):
261.12 x 163.2
Resolution:
1280 x 800
Outline Dimension (mm):
278 x 184 x 8.16
Interface:
LVDS 6/8 bits / 20pin -
13-121ZVLB00A2-S
Size (inch):
12,1
Active Area (mm):
261.12 x 163.2
Resolution:
1280 x 800
Outline Dimension (mm):
278 x 184 x 8.16
Interface:
LVDS 6/8 bits / 20pin -
13-150GMEA00A1-S
Size (inch):
15,0
Active Area (mm):
304.13 x 228.1
Resolution:
1024 x 768
Outline Dimension (mm):
326.5 x 253.5 x 12
Interface:
LVDS 6/8bit/20pins
