WF35WSWAJDNN0
TFT Size (inch):
3.5
Active Area (mm):
53.28 x 71.04
TFT Resolution:
240 x 320
Outline Dimension (mm):
61.8 x 88.5
Interface:
MCU -
WF35TTNACDNN0
TFT Size (inch):
3,5
Active Area (mm):
70.08 x 52.56
TFT Resolution:
320 x 240
Outline Dimension (mm):
76.9 x 63.9
Interface:
RGB -
WF43STVAEDNN0
TFT Size (inch):
4,3
Active Area (mm):
95.04 x 53.86
TFT Resolution:
480 x 272
Outline Dimension (mm):
105.5 x 67.2
Interface:
RGB -
WF43TTVAEDNN0
TFT Size (inch):
4,3
Active Area (mm):
95.04 x 53.86
TFT Resolution:
480 x 272
Outline Dimension (mm):
106.5 x 67.2
Interface:
RGB -
WF50ESWAGDNN0
TFT Size (inch):
5
Active Area (mm):
108 x 64.8
TFT Resolution:
800 x 480
Outline Dimension (mm):
121 x 77.4
Interface:
RGB -
WF50ETWAGDNN0
TFT Size (inch):
5
Active Area (mm):
108 x 64.8
TFT Resolution:
800 x 480
Outline Dimension (mm):
121 x 77.4
Interface:
RGB -
WF57RTQACDNN0
TFT Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
TFT Resolution:
320 x 240
Outline Dimension (mm):
144 x 89.4
Interface:
RGB -
WF57RTQAFDNN0
TFT Size (inch):
5,7
Active Area (mm):
115.2 x 86.4
TFT Resolution:
640 x 480
Outline Dimension (mm):
144 x 104.6
Interface:
RGB -
WF70A4SWAGDNN0
TFT Size (inch):
7
Active Area (mm):
152.4×91.44
TFT Resolution:
800 x 480
Outline Dimension (mm):
165.8×106.61
Interface:
RGB -
WF70RTIAGDNN0
TFT Size (inch):
7
Active Area (mm):
154.08 x 85.92
TFT Resolution:
800 x 480
Outline Dimension (mm):
164.9 x 100
Interface:
RGB -
WF80BTIAGDNN0
TFT Size (inch):
8
Active Area (mm):
176.64 x 99.36
TFT Resolution:
800 x 480
Outline Dimension (mm):
192.8 x 116.9
Interface:
RGB -
WF80BTIAGDNTA
TFT Size (inch):
8
Active Area (mm):
176.64×99.36
TFT Resolution:
800 x 480
Outline Dimension (mm):
192.8×116.9
Interface:
RGB -
WF90BTWAHLNN0
TFT Size (inch):
9
Active Area (mm):
196.608 x 114.15
TFT Resolution:
1024 x 600
Outline Dimension (mm):
211.1 x 126.5
Interface:
LVDS -
WF102ATIAGDNN0
TFT Size (inch):
10,2
Active Area (mm):
222.0 x 132.48
TFT Resolution:
800 x 480
Outline Dimension (mm):
235 x 145.8
Interface:
RGB -
WF102ATIAGDNTA
TFT Size (inch):
10,2
Active Area (mm):
222.0 x 132.48
TFT Resolution:
800 x 480
Outline Dimension (mm):
235 x 145.8
Interface:
RGB -
13-104SMLE00C1-S
TFT Size (inch):
10.4
Active Area (mm):
211.2 x 158.4
TFT Resolution:
800 x 600
Outline Dimension (mm):
243 x 184 x 6.5
Interface:
LVDS-6/8 bit -
13-104GVEB0GA0-S
TFT Size (inch):
10.4
Active Area (mm):
210.432 x 157.824
TFT Resolution:
1024 x 768
Outline Dimension (mm):
225.5 x 176.3 x 8.4
Interface:
LVDS-6/8 bit -
WF121ETWAMLNN0
TFT Size (inch):
12.1
Active Area (mm):
245.76 x 184.32
TFT Resolution:
1024 x 768
Outline Dimension (mm):
260.5 x 204
Interface:
LVDS -
13-121GMLC00B1-S
TFT Size (inch):
12.1
Active Area (mm):
245.76 x 184.32
TFT Resolution:
1024 x 768
Outline Dimension (mm):
279 x 209 x 9
Interface:
LVDS-6/8 bit -
13-121GMLC00B0-S
TFT Size (inch):
12.1
Active Area (mm):
245.76 x 184.32
TFT Resolution:
1024 x 768
Outline Dimension (mm):
279 x 209 x 9
Interface:
LVDS-6/8 bit -
13-150GMEA00A1-S
TFT Size (inch):
15
Active Area (mm):
304.13 x 228.1
TFT Resolution:
1024 x 768
Outline Dimension (mm):
326.5 x 253.5 x 12
Interface:
LVDS-6/8 bit
