FILTRERA PRODUKTER Showing all 28 results
Max Switching Current
Relay Type
Configuration
  • JRC-23F

    JRC-23F

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    1C
    Rated Load:
    1A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -30ºC to 70ºC
    Dimensions (mm):
    12.5 x 7.5 x 10

  • HFD31

    HFD31

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 70ºC
    Dimensions (mm):
    14 x 9 x 5

  • P

    P

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 70ºC
    Dimensions (mm):
    14 x 9 x 5

  • M4

    M4

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -40ºC to 90ºC
    Dimensions (mm):
    20 x 9.8 x 12

  • M1B

    M1B

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -40ºC to 90ºC
    Dimensions (mm):
    20 x 9.8 x 12

  • PS

    PS

    Max Switching Current:
    1A
    Relay Type:
    Signal SMD
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 70ºC
    Dimensions (mm):
    14 x 9 x 5

  • HFD4-V

    HFD4-V

    Max Switching Current:
    1A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    1A 30VDC, 0,3A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    10 x 6.5 x 5.65

  • HFD42

    HFD42

    Max Switching Current:
    2A
    Relay Type:
    Signal SMD
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 1A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    10,6 x 5,7 x 9

  • HFD27

    HFD27

    Max Switching Current:
    2A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    20.2 x 10 x 11.5

  • HFD23

    HFD23

    Max Switching Current:
    2A
    Relay Type:
    Signal
    Configuration:
    1C
    Rated Load:
    1A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -30ºC to 70ºC
    Dimensions (mm):
    12.5 x 7.5 x 10

  • M4S

    M4S

    Max Switching Current:
    2A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.6A 125VAC
    Operating Temperature:
    -40ºC to 65ºC
    Dimensions (mm):
    20 x 9.8 x 12

  • M1BS

    M1BS

    Max Switching Current:
    2A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.6A 125VAC
    Operating Temperature:
    -40ºC to 65ºC
    Dimensions (mm):
    20 x 9.8 x 12

  • NX

    NX

    Max Switching Current:
    2A
    Relay Type:
    Signal SMD
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15 x 7.5 x 9

  • HFD3

    HFD3

    Max Switching Current:
    2A
    Relay Type:
    Signal SMD
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15 x 7.5 x 9

  • HFD4

    HFD4

    Max Switching Current:
    2A
    Relay Type:
    Signal SMD
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    10 x 6.5 x 5.65

  • HFD3-VI

    HFD3-VI

    Max Switching Current:
    2A
    Relay Type:
    Signal/Latching
    Configuration:
    2A, 2C
    Rated Load:
    2A 30VDC, 1A 277VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15 x 7.5 x 9

  • PK

    PK

    Max Switching Current:
    2A
    Relay Type:
    Latching(2coil)
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    14 x 9 x 5

  • PL

    PL

    Max Switching Current:
    2A
    Relay Type:
    Latching(1coil)
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 0.5A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    14 x 9 x 5

  • HFD2

    HFD2

    Max Switching Current:
    3A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    3A 30VDC, 1A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    20.2 x 10.2 x 10.6

  • 4078(JRC-19F)

    4078(JRC-19F)

    Max Switching Current:
    3A
    Relay Type:
    Signal
    Configuration:
    2A, 2C
    Rated Load:
    2A 30VDC, 0.6A 125VAC
    Operating Temperature:
    -30ºC to 70ºC
    Dimensions (mm):
    21 x 10 x 12

  • HFD4-I

    HFD4-I

    Max Switching Current:
    3A
    Relay Type:
    Signal/Latching
    Configuration:
    2C
    Rated Load:
    3A 30VDC, 1A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    10 x 6.5 x 5.65

  • HFD3-I

    HFD3-I

    Max Switching Current:
    4A
    Relay Type:
    Signal/Latching
    Configuration:
    2C
    Rated Load:
    4A 30VDC, 1A 277VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15 x 7.5 x 9

  • HFD3-V

    HFD3-V

    Max Switching Current:
    4A
    Relay Type:
    Signal/Latching
    Configuration:
    2C
    Rated Load:
    2A 30VDC, 1A 277VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15 x 7.5 x 9

  • N4100

    N4100

    Max Switching Current:
    5A
    Relay Type:
    Signal
    Configuration:
    1A, 1B, 1C
    Rated Load:
    5A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -25ºC to 70ºC
    Dimensions (mm):
    15.5 x 11 x 11.5

  • HFD41A

    HFD41A

    Max Switching Current:
    5A
    Relay Type:
    Signal
    Configuration:
    1C
    Rated Load:
    5A 30VDC, 0.5A 120VAC
    Operating Temperature:
    -25ºC to 70ºC
    Dimensions (mm):
    15.7 x 11 x 12

  • HFD16

    HFD16

    Max Switching Current:
    5A
    Relay Type:
    Signal
    Configuration:
    1Z
    Rated Load:
    3A 30VDC, 1A 125VAC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15,7 x 10,6 x 11,8

  • 4100-F2

    4100-F2

    Max Switching Current:
    5A
    Relay Type:
    Signal
    Configuration:
    1A, 1B, 1C
    Rated Load:
    5A 30VDC, 2A 250VAC
    Operating Temperature:
    -25ºC to 70ºC
    Dimensions (mm):
    15.5 x 11 x 11.5

  • HFD17

    HFD17

    Max Switching Current:
    8A
    Relay Type:
    Signal
    Configuration:
    2C
    Rated Load:
    3A 30VDC
    Operating Temperature:
    -40ºC to 85ºC
    Dimensions (mm):
    15,7 x 10,6 x 12
