Bar Type TFT LCD, Bar LCD Display, Stretched Bar LCD Display
The mainstream aspect ratio of the TFT LCD panel in the market is 4:3 or 16:9. But for some applications, bar type shape of display panel would be much better than the current mainstream 4:3 or 16:9 to display the required information. Bar Type TFT-LCD displays are perfect for industrial equipment, automotive application, server system, POS system, dynamic information displays and advertising display. We offer different sizes Bar Type TFT (Stretched Bar LCD Display) including sizes of 3.9 inch, 4.6 inch and 5.2 inch. In order to meet with customers requirement especially for industrial applications, we develop more derivative solution from these Bar type TFT as below:
- With screw hole on frame version option.
- With Capacitive Touch Panel or Resistive Touch Panel option.
- High Brightness version option.
- Controller board version option (WF52Q).
Fler Bar Type TFT finns i sortimentet än vad du ser på sidan. Kontakta oss.
-
WF39ATIASDNN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,50 x 40,64
Interface:
RGB -
WF39BTLASDNN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39BTLASDNGA
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39BTLASDNT0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39BTZASDNN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39BSQASDNN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39CTIASDNN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39CTIASDNT0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39CTIASDNG0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
105,5 × 37
Interface:
RGB -
WF39QTIBSDBN0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
122 × 44
Interface:
MCU -
WF39QTIBSDBG0
Size (inch):
3,9
Active Area (mm):
95,04 x 25,34
Resolution:
480 x 128
Outline Dimension (mm):
122 × 44
Interface:
MCU -
WF46ATIATDNNA
Size (inch):
4,6
Active Area (mm):
108 x 43,2
Resolution:
800 x 320
Outline Dimension (mm):
120,70 x 56,16
Interface:
RGB -
WF46ATIATDNNA
Size (inch):
4,6
Active Area (mm):
108 x 43,2
Resolution:
800 x 320
Outline Dimension (mm):
120,70 x 56,16
Interface:
RGB -
WF52ATLASDNN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ATLASDNG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ATZASDNN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ATZASDNG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ASLASDNN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ASLASDNG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ASZASDNN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52ASZASDNG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,40 x 49,87
Interface:
RGB -
WF52QTLBSDBN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
180,00 x 65,00
Interface:
8080/MPU -
WF52QTLBSDBG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
180,00 x 65,00
Interface:
8080/MPU -
WF52QTZBSDBN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
180,00 x 65,00
Interface:
8080/MPU -
WF52QSZBSDBN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
180,00 x 65,00
Interface:
8080/MPU -
WF52ATLASDNT0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52ATLASDNGA
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52ASLASDNGA
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52BTIASDNN0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52BTIASDNT0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52BTIASDNG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
140,4 × 49,87
Interface:
RGB -
WF52QTLBSDBG0
Size (inch):
5,2
Active Area (mm):
127,15 x 33,91
Resolution:
480 x 128
Outline Dimension (mm):
180 × 65
Interface:
MCU
